Lifting columns

DL11

Long-stroke electric column allowing smooth and low-noise adjustment in various desk applications and TV / monitor stands. The 3-part construction ensures short installation dimension. Come with optional LINAK PIEZO anti-collision system.

  • Lifting column DL11

Product description

DL11

The DL11 DESKLIFT is a compact round 3-part lifting column, which is a perfect choice for a wide range of different desk applications, such as office desks or conference desks.

The 3-part construction ensures a short installation dimension combined with a long stroke length, making the DL11 an optimum choice whatever the height of the person using the desk.

The DL11 has the same outer dimensions and mounting holes as the 2-part DL10 column, which makes them compatible and they can be used in the same tabletop and table foot construction.

The DL11 is available in several standard colours to fit into a wide range of desk designs. Optional PIEZO™ (collision protection) can be chosen. PIEZO minimises the risk of material damages to a desk caused by collision with an obstacle.

The DL11 is compatible with the standard DESKLINE control box (CBD). Whichever box is preferred, they all ensure a very low and pleasant noise level and a wide range of options.

The DL11 is also available in an extended version called XL, which is optimised for adjustment of display and monitor stands.

  • Max. thrust: 800 N
  • Max. speed: 38 mm/s
