Accessories

Flange Mounting Bracket

Mounting bracket for easy installation of electric actuators on industrial valves

Flange Mounting Bracket

Product description

Flange Mounting Bracket

The Flange Mounting Bracket facilitates easy flange mounting of LINAK electric actuators on industrial valves typically used in wastewater treatment facilities.

The bracket interface dimensions comply with industry standards ISO 5210 and ISO 5211, and fit flange types F07 and F10.

  • Bracket for flange mounting of actuators
  • Complies with ISO 5210 and ISO 5211
  • Flanges F07 and F10

Product data sheet

Flange Mounting Bracket

View the data sheet as an online magazine or download the PDF.

View

2D / 3D

2D Drawings

3D Models

Brochures & manuals

Flange Mounting Bracket user manual

This user manual will tell you how to use your LINAK bracket for flange mounting of your LINAK electric actuator on industrial valves.

View

Focus on wastewater treatment

In the wastewater industry easy control and monitoring are key elements for ensuring optimal day-to-day running of wastewater facilities. Learn more about LINAK actuator solutions for wastewater handling in this brochure.

View

TECHLINE product overview

Explore the wide variety of tough and powerful TECHLINE products. Built to last, built for hard work and built for work in harsh environments.

View

Related applications

Wastewater treatment

Related business areas

Solutions for valves

Related products

LA36
linear actuators

LA36

  • Max thrust: 10,000 N
  • Max speed: 160 mm/s
  • Stroke length: 100-999 mm
LA37
linear actuators

LA37

  • Max thrust: 15,000 N
  • Max speed: 3.5 mm/s
  • Stroke length: 600 mm
