Danfoss PLUS+1® – fast integration of electric actuators into heavy-duty machinery
LINAK®-Danfoss® collaboration makes it possible for engineers to add electric actuators when designing intelligent off-highway vehicles and other heavy-duty vehicles.
What is Danfoss PLUS+1?
The PLUS+1 is a unique system development platform or tool for engineers, who design intelligent off-highway vehicles for harsh environments. Through an intuitive programme interface called PLUS+1® GUIDE, the design engineer can use it to add, move, drag, and drop all components and parts necessary to meet the requirements of a modern vehicle.
Adding a specially tailored compliance block to the Danfoss PLUS+1 platform allows engineers, who are working with all sorts of heavy-duty machinery, to include electric actuators when designing applications.
Saving time during the design phase
Through a close collaboration between the two industry segments LINAK TECHLINE® and Danfoss Power Solutions, a new extension to the Danfoss PLUS+1 development tool enables engineers to add electric actuators when designing intelligent off-highway vehicles and other heavy-duty machinery.
Many engineers designing heavy-duty machinery for construction, mobile agriculture and outdoor power equipment use the Danfoss PLUS+1 platform during the design phase.
Through a series of compliance blocks, the platform allows engineers without any expertise in software development to select, drag, and drop components when they design new machinery.
Almost as easy as plug and play
The interface holding the components together is called PLUS+1 GUIDE. It is a development tool owned by Danfoss Power Solutions, which allows the user to combine graphic symbols and components and create the complete software vehicle control systems. This kind of modular programming offers the development engineer far more options and makes it possible to create optimum solutions much faster than usual.
A quick way to add electric actuators
Already fully compatible with CAN bus systems (via CAN SAE J1939), LINAK actuators are easy to integrate when modern vehicles require a durable movement/adjustment solution. Combined with decades of experience in making solutions for systems operating in harsh environments, LINAK brings the most tried-and-tested technology to the Danfoss PLUS+1 platform.
LA14
Linear actuators
Extremely durable short-range linear actuator for applications operating in rough environments. Ensures reliable performance in temperatures ranging from -40 to +85 Celsius.
- Max. load: 750 N
- Max. speed: 45 mm/s
- Stroke length: 19-130 mm
LA25
Linear actuators
Compact designed linear actuator ideal for narrow spaces. Comes with a high IP degree and aluminium housing and is suited to operate in almost any conditions.
- Max. load: 2,500 N
- Max. speed: 25 mm/s
- Stroke length: 20-600 mm
LA33
Linear actuators
The linear actuator LA33 from LINAK combines compact design with powerful performance. Available with high-speed option, I/O and low-noise gear option for even more customisation possibilities in demanding applications.
- Max. load: 5,000 N
- Max. speed: 70 mm/s
- Stroke length: 100-600 mm
LA36
Linear actuators
Extremely powerful linear actuator made by LINAK. Up to 6,800 N load, or up to 160 mm/s. Designed to operate in extreme conditions. A solid choice for industrial and agricultural applications.
- Max. load: 6,800 N
- Max. speed: 160 mm/s
- Stroke length: 100-1200 mm
LA37
Linear actuators
Extremely powerful linear actuator able to create reliable movement even in very harsh environments. It comes with LINAK IC Integrated Controller™ and a wide range of industrial control interfaces.
- Max. load: 15,000 N
- Max. speed: 10 mm/s
- Stroke length: 100-600 mm
LA76
Linear actuators
Versatile electric linear actuator that delivers both robustness and long-term reliability. It excels in challenging environments and is a wise choice for a wide array of industrial machinery and applications that require high-level performance.
- Max. load: 6,800 N
- Max. speed: 142 mm/s
- Extended service life
LA77
Linear actuators
Powerful electric linear actuator designed to handle high loads and demanding environments. It delivers long-lasting reliability as well as a wide choice of industrial interfaces.
- Max. load: 15,000 N
- Max. speed: 7 mm/s
- Extended service life
