With more people in need of care, but fewer hands to do the caring, there is an urgent need for intelligent solutions that enable efficient workflows and increase the comfort and safety of patients. This is why 'Care for Tomorrow Today' has become the mindset we apply to everything we do at LINAK.
We believe it is crucial to think ahead. Only by doing so can we provide the world with advanced ergonomic solutions that will make a significant difference. And we hope you will join us on the journey.
Make a positive difference
We encourage you to infuse your craftsmanship with our Intelligent Care Solutions™ to take essential products such as nursing home beds, wheelchairs, patient lifts and examination tables to the next level. For the good of patients and carers, as well as for society.
Or, in other words: 'Care for Tomorrow Today'.
“Intelligent care solutions, such as intelligent beds, do not mean we visit the user any less. What technological advances do is enable us to schedule visits when our help is of most value to the user. That means a lot to the user and their relatives – and to us.”
Henriette Petersen, Carer.
Dental chairs
LINAK actuator systems help create smooth movement and comfort in dental chairs.
Homecare beds
The ageing population, fewer hands to take care of the patients and shorter hospital stays drive the need for homecare beds. Using LINAK actuator solutions allows for optimal movement, supporting patient well-being, safety and mobility.
LINAK LIFT™
Dedicated, streamlined, efficient and easy to use LINAK solutions for your patient lift.
Hospital beds
The ageing population and fewer hands to take care of the patients drive the need for hospital beds. Using LINAK actuator solutions allows for optimal movement, connectivity to the hospital information facility and digital services – all increasing the caregiver efficiency.
Nursing home beds
The ageing population and fewer hands to take care of the patients drive the need of nursing home beds. Using LINAK actuator solutions allows for optimal movement, supporting patient well-being and safety, as well as connectivity to the nursing home information facility and digital services – all increasing the caregiver efficiency.
Wheelchair solutions
LINAK actuators help create precise and low-noise adjustment of height, leg support, and backrests in modern wheelchairs.
ACC
Controls
Attendant Control Compact (ACC). Cost and size optimised control unit with up to 11 buttons. Comes with optional lock-out/key function. Compatible with OpenBus interface control boxes.
- OpenBus™
- Up to 11 buttons, lockable
- IPX6
ACK
Controls
Attendant Control Keypad (ACK) is used as nurse controls or side panel handset. Able to control up to five channels. Optional colour and graphic design customisation.
- OpenBus™
- Up to 11 buttons
- Lockable
ACL
Controls
Attendant Control Lock (ACL) is a one-turn control meant to disconnect all other adjustment functions in for instance hospital beds and nursing home beds.
- Analogue or OpenBus™
- Global lock
- IPX6
ACO
Controls
Attendant Control OpenBus (ACO) is a flexible control unit with numerous optional functions. Can also be used as handset keys and/or lock out controls. Compatible with OpenBus control boxes.
- OpenBus™
- Up to 20 buttons
- IPX6 Washable DURA™
BAJ
Accessories
The BAJ is a lead acid battery for use together with the modular JUMBO™ patient lift system. It offers variable and reliable battery capacity together with easy mounting, charging and replacement.
- Lead acid battery for JUMBO™ system
- Capacity 2.29 Ah
- IPX5
BAJL
Accessories
Li-Ion battery solution for the JUMBO™ system, ideal for mobile applications such as patient lifts. BAJL offers reliable and stable performance with a long lasting battery solution.
- Li-Ion battery for JUMBO™
- Capacity 3.3 Ah and 6.6 Ah
- IPX5
BL1
Lifting columns
Compact and powerful (2,000 N push) 3-part lifting column with up to 400 mm stroke. Smooth design with exchangeable cable connection and optional integrated cable throughput.
- 3-stage lifting column
- Max. speed: 18 mm/s at 2,000N
- IPX6
CA30
Control boxes
2-channel IPX6 Washable DURA™ control box for LINAK actuators. Comes with unique slide-on brackets for easy mounting, integrated cable lock system and SMPS.
- 2-channel, analogue
- Power: 120 W Switch Mode Power Supply
- IPX6 Washable DURA™
CA40
Control boxes
4-channel IPX6 Washable DURA™ control box for electric actuators. Comes with unique slide-on brackets for easy mounting, integrated cable lock system and SMPS.
- 4-channels, analogue
- Power: 120 W Switch Mode Power Supply
- IPX6 Washable DURA™
CB6P2
Control boxes
Light-weight LINAK control box with SMPS. Based on OpenBus technology, yet meeting existing demands for analogue systems. Ideal for parallel drive setups.
- 4 channels
- SMPS
- Analogue/OpenBus
CBJ Care
Control boxes
CBJ Care is part of the reliable and flexible JUMBO™ system, ideal for patient lifts. The control box provides safe and comfortable lifting in daily use. Safety features such as soft start/stop and emergency lowering ensure a safe patient transfer. CBJ Care offers favourable features as maximum weight setting and data read-out either via display or Service Data Tool.
- 3-channel, OpenBus™
- Service data
- Redundant control
CBJ Home
Control boxes
LINAK control box with built-in battery. Used in JUMBO systems with one or two actuators. Ensures comfort and comes with soft-start/stop function, emergency lowering, and recordable max SWL.
- 2-channel, analogue
- Capacity 2.9 Ah battery
- IPX4
CO61 MK2
Control boxes
Innovative 4-channel OpenBus™ control box for programmable actuator systems in healthcare. Ideal for hospital beds thanks to the IPX6 Washable DURA™ water protection. Comes with full bridge, optional Bluetooth technology, SMPS and intuitive cable management.
- 4-channel, OpenBus™
- Power: 200 W Switch Mode Power Supply
- IPX6 Washable DURA™
DPH Medical
Controls
The LINAK desk panel DPH is an aesthetic control unit ideal for linear actuator systems used in, for example, treatment couches, chairs, patient lifts, and medical tables.
- Analogue or OpenBus™
- Two buttons
- Easily integrated in the application
FPP
Controls
Flexible Patient Panel (FPP). Comes with a flexible arm making it ideal for hospital and nursing home beds. It enables patients to control and adjust applications such as backrest and leg support.
- OpenBus™
- Up to 20 buttons
- IPX6
FS
Controls
LINAK Foot Switch (FS) is a control unit for electric linear actuator systems. Ideal for physiotherapist couches, dental chairs, and various industrial workstations.
- Analogue or OpenBus™
- Up to 2 channels
- IPX6
FS3
Controls
The LINAK FS3 is a foot switch control designed for medical equipment and healthcare applications. It allows staff / practitioners to have both hands free when attending to the patient or client. This highly ergonomic control comes with one or two channels as standard, and is also available in a wireless version.
- Analogue, OpenBus or Wireless
- Unique design
- Bed or floor model
HB30
Controls
LINAK handset control unit, ideal for actuator systems in patient lifts, treatment chairs, couches and tables. Available for both analogue and OpenBus control boxes.
- OpenBus™ or analogue
- Up to 8 buttons LEDs
- IPX6
HB80
Controls
IPX6 Washable DURA™ handset control for LINAK actuator systems in hospital beds, treatment couches, or patient lifts. Comes with 10-12 ergonomic buttons and optional back light function.
- OpenBus™
- Up to 12 buttons
- IPX6 Washable DURA™
HD80
Controls
LINAK HD80 is a durable handset control for linear actuators in all types of medical applications. Comes with lock function to ensure safety for patients. Comes as IPX4 or IPX6 Washable DURA™ with intuitive dome keys.
- OpenBus™
- Up to 12 buttons, lockable, LEDs
- IPX6 Washable DURA™
HL70
Controls
LINAK handset control for actuators in healthcare applications where a lock function is required to ensure safety for patients. Able to control up to five actuators.
- OpenBus™ or analogue
- Up to 10 buttons, lockable
- Up to IPX6
LA23
Linear actuators
Powerful linear actuator with compact design to fit into narrow spaces. A high push/pull force makes it ideal for almost any application.
- Max. load: 2,500 N push
- Max. speed: 22.0 mm/s
- IPX6 Washable DURA™
LA31 CARELINE
Linear actuators
Strong and low-noise linear actuator designed for beds in homecare, nursing home or hospital settings. Works with all LINAK healthcare control boxes. Classified IPX6. Max thrust: 6,000 N.
- Max. load: 6,000 N push (4,000 N pull)
- Max. speed: 32.0 mm/s
- IPX6
LA34
Linear actuators
Powerful linear actuator (10,000 N push / 4,000 N pull) in a compact design. Made partly of low weight composite materials. Ideal for both medical and industrial applications.
- Max. load: 10,000 N
- Max. speed: 18.0 mm/s
- IPX6
LA40
Linear actuators
Durable actuator with powerful lift (up to 8,000 N) made for a range of healthcare applications, such as beds, couches and chairs for treatment, wheelchairs, operating tables, patient lifts and dental chairs.
- Max. load: 8,000 N
- Max. speed: 16.0 mm/s
- IPX6 Washable DURA™
LA44
Linear actuators
Very powerful linear actuator with several safety features. Ideal for applications such as patient lifts, dental chairs and various healthcare beds. Max thrust: 12,000 N push.
- Max. load: 12,000 N
- Max. speed: 14.0 mm/s
- IPX6
MBJ
Accessories
MBJ is a mounting bracket designed for JUMBO™ products for use in patient lifts.
- Mounting bracket for JUMBO™
Massage Motor Medical
Accessories
The LINAK massage motor can add comfort to many types of adjustable medical applications. Ideal for treatment couches and tables. Simple to mount.
- OpenBus
- Safety thermo switch
- One hand control
UBL2
Accessories
The Under Bed Light, UBL2, provides powerful multicolour lighting with effective light distribution for hospital and care beds equipped with LINAK actuator systems. UBL2 features an optional IPX6 Washable DURA™ classification.
- Multicolour light
- Customisable
- Status by colour
